Interested in RIM RR24C02 road bike/cyclocross Contact Us!

All wheels are 100% customizable at Light Bicycle. If your preferred specs are not listed, feel free to contact us (sales@lightbicycle.com) with your special requirements described.


RIM SPECS

  • Use road bike/cyclocross
  • Size 700c
  • Material full carbon Toray T700
  • Type clincher
  • Weight 390g+/-15
  • Tubeless ready
  • Spoke Hole 16H to 36H
  • Internal hole customized
  • ERD 592mm
  • Inner width 15.4mm
  • Outer width 23mm
  • Depth 24mm
  • Max weight limit 110kg
  • Max spoke tension 180kgf
  • Max tyre pressure 160psi
  • Finish matte/glossy
  • Decal customized
  • Weave UD/3K/12K
  • Warranty 15 Months
  • Standard En Standard

Read more for actual road tire width

TECH

WARRANTY

For Non-Pro Series Rims: From the date of purchase, 3-year Standard Warranty.

For Pro Series Rims: From the date of purchase, 5-year Pro Warranty as standard and an upgraded optional lifetime Premium Warranty with minimum charge.

Crash Replacement: It is applicable with the same period as the warranty time range that you purchased for the rims with 10% /25% discount for Non-Pro series /Pro series.

Specs

Warranty

In The Box

Rims

Our Pro series comes with a 5-year warranty (lifetime optional), while the non-pro with a 3-year warranty and crash replacement.)

  • Use: road bike/cyclocross
  • Size: 700c
  • Material: full carbon Toray T700
  • Type: clincher
  • Weight: 390g+/-15
  • Tubeless: ready
  • Spoke Hole: 16H to 36H
  • Internal hole: customized
  • ERD: 592mm
  • Inner width: 15.4mm
  • Outer width: 23mm
  • Depth: 24mm
  • Max weight limit: 110kg
  • Max spoke tension: 180kgf
  • Max tyre pressure: 160psi
  • Finish: matte/glossy
  • Decal: customized
  • Weave: UD/3K/12K
  • Warranty: 15 Months
  • Standard: En Standard

Read more for actual road tire width

Full Custom

Get in touch with us (sales@lightbicycle.com) to discuss in detail your customization request.

  • Hole: Hole Count, Spacing, Pattern, Drilling Angle, Diameter
  • Finish: Matte, Glossy, Satin, Colored Paint
  • Weave: UD, 3K, 3K Twill (Vertical/Horizontal), 12K, 12K Twill (Vertical/Horizontal), Braided UD, Hexa-Comb
  • Brake Track: UD, 3K, 3K Twill (Vertical/Horizontal), 12K, 12K Twill (Vertical/Horizontal), Braided UD, Hexa-Comb
  • Weight Style: Standard, Flyweight, Ultra-Light, Heavy Duty, HD+

Explore more Full Custom services

Gallery

Benno's : My 2015 Defy with custom Light-Bicycle rims. I had custom graphics applied to some 24mm 3k matte rims and laced them to Extralite Cyber SPD hubs using Sapim CX-Ray spokes. Came out to 1199grams but more importantly they ride soooooo much smoother than the Zipp 202's that came with the bike. Very happy customer. Thanks Kartrin and Light-Bicycle!
Canada
3

View More Reviews >>

COMMENTS

C

Chris 2017/06/01

I ordered the 24 wide rims is it possible to set up tubeless with a 25 tire??

LightBicycle 2017/06/02

Hello Chris, I double checked with production line, and the rims have been shipped out already. Thanks, Lightbicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

D

David 2017/05/18

Can the 23 X 24mm 700C clincher rim be drilled for 16-8 spoke lacing? Also, is it compatible with 23 or 25mm tubless tyres?

LightBicycle 2017/05/19

Hello David, Thanks for your inquiry. The 24mm clincher rim can be drilled in 24H with 2:1 drilling for 16-8 spoke lacing. Please find attached drilling pattern, which do you prefer? Recently, some customers gave us feedback that it is a little difficult to do the tubeless setups on RR24C02. So we’d like to recommend the 25mm wide U shape 25mm rim which is easy to setup tubeless tyres. You only have to use tubeless tape, sealant and tubeless tire. Then the rims can ride tubeless perfectly. Also, the wider rim is much stronger, and will work with 23C or 25C tubeless tyres well. Thanks, Lightbicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

E

Erick 2017/03/07

Hi, i was wondering if a couple of 32h 24mm clincher carbon rims without brake surface could be build with a pair of phil track hubs with large flange?. I want to build the front wheel with diametral or straigh spokes and the rear wheel whit normal cross build, is there some problem with that kind of construction? or the rims have a specific way to be build? I dont like the 25 mm U shape rim because de inner width is too much big, in that case i must use like 28c tires as minimun and for track that doesnt help. Thank you for your time, sorry for my bad english. Grettings from Bogota, Colombia.

LightBicycle 2017/03/08

Hello Erick, Thanks for your inquiry. Our 24mm clincher rim will work with Phil track hubs. It is the same as normal wheels building. Yes, U25mm rim is much wider but stronger. If you use narrower tires like 23C, then go with 24mm rim. Thanks, Lightbicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

M

Mark 2016/09/16

Good morning, I would like to use a pair of rims on a tandem. Is that possible? Can it hold the weight of the German built Rohloff internally geared hub? The combined weight (riders and bike) are about 300pounds.

Light-Bicycle 2016/09/18

Hello Mark, Sorry for the late reply. Because we were on vacation in last 3 days. It is okay to use our rims on a tandem. However, we suggest you to go with the U shape 55mm depth rims. It is much deeper, stronger, and able to hold the geared hub. Does that work for you? I’m afraid that the 24mm is not strong enough for a tandem. Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

G

GIUSEPPE 2016/08/01

Good evening Sorry for my bad English I wanted to know if you had carbon rims for clincher 32 rays. The circle will be paired with the PowerTap hub. Thank you Good evening Sorry for my bad English I wanted to know if you had carbon rims for clincher 32 rays. The circle will be paired with the PowerTap hub. Thank you Good evening Sorry for my bad English I wanted to know if you had carbon rims for clincher 32 rays. The circle will be paired with the PowerTap hub. Thank you

Light-Bicycle 2016/08/02

Hello GIUSEPPE, Thanks for your inquiry. Do you like the rims drilled with 32H holes? If so, that is fine. Do you need the brake tracks on rims? Is it for disc brake or normal road rims with brake surface? Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

J

Jamie 2016/03/12

Light Bicycle, I weigh around 60kg and I am looking for a reliable, lightweight wheelset for my trip to the alps this year. I am looking for a weight around 1200g but what is the lightest you do. Regards, Jamie

Light-Bicycle 2016/03/14

Hello Jamie, Thanks for your inquiry. According to your details, we’d like to recommend the U25mm wheelset as following specs. -Rims: RRU25C02, UD mate, 20H/24H, 405 /-15g. -Hubs: Black, Bitex RAF10/ RAR9 J-bend (258g/pair, lightest hubs) or DT 240S straight pull non disc hubs (319g/pair). Sorry, we don’t have cyber sp hubs. -Spokes: Black, Pillar x-tra 1420 aero -Nipples: Alloy or brass? Silver or black? Thanks, Lightbicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

S

SHINYA 2016/01/31

Can you center drilling? for 2to1 spoke reyout.

Light-Bicycle 2016/02/01

Hello SHINYA, Thanks for your inquiry. The 24mm clincher rim can not be manufactured with center drilling for 2:1. Sorry for the inconvenience. We’d like to recommend the wider U shape 25mm clincher rim which can be drilled with angle /-6. Do you like it? The aerodynamic shape makes road tubeless rims lightweight but still stiff, keeping them stable in cross winds. Rim profile attached for reference. RRU25C02 (25mm width U shape): 405 /-15g, $159/pcs RR24C02 (23mm width V shape): 400 /-15g, $150/pcs Thanks, Lightbicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

M

Michiel 2015/09/29

Hi there, I already use your MTB rims and am looking for a rim that is light BUT has to have good braking performance in wet conditions. Do these rims have similar performance as alu-rims or Mavics ceramic rims? And what brakepads do you advise for DA9000 brakes? Thanks, Michiel

Light-Bicycle 2015/09/30

Hi Michiel, Currently, there is a new 25mm wide 25mm depth clincher U shape rim. This rim is strong and durable. I recommend you this rim. Please find the attached cross-section drawing of the rim. Is it OK for you? https://www.lightbicycle.com/Carbon-700C-25mm-wide-road-rim-clincher-25mm-deep-U-shape-tubeless-compatible-with-basalt-braking-surface.html#.Vgu8i_mqpBc RRU25C02: USD159/pcs, 400 /-15g For the rims, do you prefer UD, 3k or 12k? Matte or glossy? Front 20H/rear 24H? http://www.flickr.com/photos/light-bicycle/sets/72157631432948364/detail/ The road rims are carbon fiber materials and with basalt braking track(no aluminum here). If you use them in normal condition, the braking track will work well. It's OK to use the brake pads which are specially designed for carbon rims. We also sell brake pads here. Please find the attached picture for your reference. Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

T

Thomas 2015/08/04

are the max. 110kg riders weight for these rims real? thanks from berlin germany, thomas

Light-Bicycle 2015/08/04

Hello Bill, Thanks for your inquiry. Currently, we only have 23mm wide 38mm depth & 25mm wide 35mm depth tubular rims, no 30mm depth rim. The 25mm width rim is much wider and stronger. Most of our customers chose this new one, and it is with nice feedback. We are sure that you will like it. RRU35T02 (25mm wide U-shaped 35mm tubular rim): 370 /-15g, USD145/pcs RR38T02 (23mm wide 38mm clincher rim): 340 /-15g, USD133/pcs Please find attached rims cross-section drawings. For rim weave, do you prefer 3k, 12k or UD? Matte or glossy? 20H/24H? Please find below link. http://www.flickr.com/photos/light-bicycle/sets/72157631432948364/detail/ Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

S

SHINYA 2015/07/23

This carbonrim is different now weight. 360g>390g Change the specifications?

Light-Bicycle 2015/07/27

​Hello SHINYA, Thanks for your inquiry. We have revised the road rim’s braking surface, and it is with basalt braking track now. It is more safety, high durability and wear reduced. So, the rims weight will be around 30g added. Is that ok for you? Currently, we also have new 25mm wide U-shaped 25mm clincher rim. It is much wider and stronger. Most of customers choose this one and it is with nice feedback. We are sure that you will like it. Please find attached rims profiles. RRU25C02 (25mm wide U-shaped 25mm clincher rim): 390 /-15g, USD159/pcs RR24C02 (23mm wide 24mm clincher rim): 390 /-15g, USD150/pcs For rim weave, do you prefer 3k, 12k or UD? Matte or glossy? 20H/24H? Please find below link. http://www.flickr.com/photos/light-bicycle/sets/72157631432948364/detail/ Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

J

javi 2015/07/01

HELLO how are Light-Bicycle decal in carbon 24mm rim road bike 700c clincher? Can i chosse the color, and there are different types of LB decals? how it works? Thanks

Light-Bicycle 2015/07/01

Hello Javi, Thanks for your inquiry. For decals, it is free to design light-bicycle graphics on rims. Please find attached design of 24mm clincher rims with decals we have done for customers. Which do you prefer? You also can email us the graphics & color you like, then we will design it on rims for your check. Normally, it is USD65 for one-color or two-color graphics. For rims, we’d like to recommend the 25mm wide U-shaped 25mm clincher rim. It is much wider and stronger. Also, the rim is tubeless compatible. Would you like to have a try? RRU25C02 (25mm wide U-shaped 25mm clincher rim): 400 /-15g, USD159/pcs RR24C02 (23mm wide 24mm clincher rim): 400 /-15g, USD150/pcs For rim weave, do you prefer 3k, 12k or UD? Matte or glossy? 20H/24H? Please find below link. Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

C

Cheolmin 2015/06/28

Hi. I'm planning to build a pair of wheelset. I'd like to order 2 rims and sapim spokes. If I let you know spoke size what I need, can you send me it together? Thanks

Light-Bicycle 2015/06/29

Hello Cheolmin, Thanks for your inquiry. Sorry, do you like to order the wheelset (front wheel rear wheel) or rims only? We also can sell the rims and spokes to you, then you can build the wheelset by yourself. RR24C02 (23mm wide 24mm clincher rim): 390 /-15g, USD150/pcs Please find attached rim cross-section drawing. For rim weave, do you prefer 3k, 12k or UD? Matte or glossy? 20H/24H? Please find below link. http://www.flickr.com/photos/light-bicycle/sets/72157631432948364/detail/ Currently, we also have new 25mm wide U-shaped 25mm clincher rim. It is much wider and stronger. Also the new U25mm rim is tubeless compatible. Do you like it? It is USD159/pcs Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

J

Jack 2015/05/12

Hi, do you have 25mm wide U-shaped 25mm clincher rims? Also will you be able to built those rims on track hubs with CX-Ray spokes? Do let me know what hubs you carry? Looking at 20H front and 24H rear. Thanks.

Light-Bicycle 2015/05/13

Hello Jack, Thanks for your inquiry. -Yes, we have the new 25mm wide U-shaped 25mm clincher rims. Attached is the rim cross-section drawing. For rim weave, do you prefer 3k, 12k or UD? Matte or glossy? Please find below link. http://www.flickr.com/photos/light-bicycle/sets/72157631432948364/detail/ -For hubs, it is Novatec A565SBT/ A566SBT in 20H/24H. Please find attached picture. Is that what you like? -For spokes & nipples, Sapim cx-ray spokes & nipples in black are available. Wheelset price: USD568/pair Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

B

Brian 2015/05/08

Hi, I'm interested in a set of these - 32 hole, matte UD, no braking surface with DT Swiss 240 centerlock disc hubs for 11 speed Shimano. Standard QR in the front and 135mm QR in the rear. I'd like to build them up myself with DT Swiss Aerolite spokes with alloy nipples in 3x. Or if you can't get those spokes, then just get the rims and hubs from you along with your recommended spoke lengths. Thanks, Brian

Light-Bicycle 2015/05/08

Hello Brian, Thanks for your inquiry. For rims, we’d like to recommend new 25mm wide U-shaped 25mm clincher rims. It is much wider and stronger. Do you like it? Because the 24mm clincher rims can not ride tubeless. RRU25C01 (25mm wide U-shaped 25mm clincher rim): 390 /-15g, USD159/pcs RR24C02 (23mm wide 24mm clincher rim): 390 /-15g, USD150/pcs It is ok to do UD matte, 32H, and no braking surface. Please find attached rims cross-section drawings. For hubs, we have black DT Swiss 240 J-bend centerlock disc hubs front standard qr/ rear 135mm standard qr for Shimano 11s. It is USD460/pair. For spokes, we only have black DT competition spokes/ Sapim cx-ray/Pillar x-tra 1420 aero spokes, no DT Swiss Aerolite spokes. Sorry for the inconvenience. Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

P

Paul 2014/07/10

when building the wheels is a washer between the nipple and rim required?

Light-Bicycle 2014/07/11

Hello Paul, Please find the attached cross-section drawing of the 23mm wide 24mm clincher rim. For the rims, do you prefer UD, 3k or 12k? Matte or glossy? Front 20H/rear 24H? Thanks, Light-bicycle

R

Rob 2015/03/20

Hi Just enquiring about a pair of cyclocross wheels made up with these rims. They need to be 11 speed hubs shimano and discprices and weights please

Light-Bicycle 2015/03/21

Hello Rob, Thanks for your inquiry. We can build the 24mm clincher disc wheelset as following specs. -Rims: 23mm wide 24mm clincher rims, 360 /-15g. Please find attached rim cross-section drawing. For rim weave, do you prefer 3k, 12k or UD? Matte or glossy? Front 24H/ rear 24H? Please find below link. http://www.flickr.com/photos/light-bicycle/sets/72157631432948364/detail/ -Hubs: Novatec D711/D712 qr for Shimano 11s disc. Do you prefer black/red/white? -Spokes: Black, Pillar Aero X-TRA 1420 aero -Nipples: Pillar PT 734. Do you like black, blue, gold, green or red? Currently, we also have new 25mm wide U-shaped 35mm clincher wheels. It is much wider and stronger. Do you like it? Thanks, Light-bicycle

REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

See all 25 customer reviews>>
