Build Your Falcon RIM R35T

All wheels are 100% customizable at Light Bicycle. If your preferred specs are not listed, feel free to contact us (sales@lightbicycle.com) with your special requirements described.

Global Shop

NA Shop

EU Shop

AU Shop

Ships worldwide. See what's on sale>>

Drain Hole This is a required option.

With Drain Holes

Center Channel Hole This is a required option.

No Access Holes

Version This is a required option.

Front Flyweight / Rear Standard

Weave This is a required option.

Braided UD

DEFAULT SETTINGS

RIMS

Matte, UD, hook, blank (no decal), 24h

Paintless, UD, blank (no decal), 28h, with access holes

Standard, paintless, hook, blank (no decal), 24h, with drain holes, without access holes

HUBS

DT Swiss 350 Straightpull Centerlock Shimano Road 11s 36t

12/100mm (F) & 12/142mm (R)

DT Swiss 350 Straightpull Centerlock Sram XD 18t

15/110mm (F) & 12/148mm (R) boost

DT Swiss 350 straightpull centerlock Shimano Road 11s 36t

12*100mm (F) & 12*142mm (R)

SPOKES & NIPPLES

Sapim CX Sprint-rear drive side / CX Ray-other sides

Sapim aluminum black external

Sapim CX Ray & Sapim aluminum black external

Sapim CX Sprint-rear drive side / CX Ray-other sides

Sapim aluminum black external

ACCESSORIES

2 valves & 1 spare 18t ratchet

2 valves & 2 adapters (centerlock to 6-bolt)

2 valves & 1 spare 18t ratchet

Note: the wheelset price includes the warehouse transfer cost ($80).

Piece Weight: g+/-

Subtotal: USD +

Lead time: typically ships in 2 days

ADD TO CART You missed some options.

We do not stock this item at the European warehouse. See what we stock currently.

You can order this product from our Global or North American warehouse.

Please fill out this form with your special requests if you want to customize it. We will get back to you in 24hrs via email.

Center Channel Hole This is a required option.

No Access Holes

DEFAULT SETTINGS

RIMS

Matte, UD, hook, blank (no decal), 24h, with drain holes

Paintless, UD, blank (no decal), 28h, with access holes

HUBS

DT Swiss 350 Straightpull Centerlock Shimano Road 11s 36t

12*100mm (F) & 12*142mm (R)

DT Swiss 350 Straightpull Centerlock Sram XD 18t

15/110mm (F) & 12/148mm (R) boost

SPOKES & NIPPLES

Sapim CX Sprint-rear drive side / CX Ray-other sides

Sapim aluminum black external

Sapim CX Ray & Sapim aluminum black external

ACCESSORIES

2 valves & 1 spare 18T ratchet

2 valves & 2 adapters (centerlock to 6-bolt)

Note: the wheelset price includes the warehouse transfer cost ($80).

Piece Weight: g+/-

Subtotal: USD + (discount price)

Lead time: typically ships in 3 business days

ADD TO CART You missed some options.

We do not stock this item at the Australian shop. See what's available.

You can order this product from our Global / NA shops.

Please fill out this form if you are looking for a custom wheelset.

We'll get back to you soon to study the customization requests via email.

Our apologies, we do not offer this item at the Global warehouse.

Please order from other warehouses. Feel free to contact us (sales@lightbicycle.com) if you want to customize. We’ll get back to you in 24hrs.

Our apologies, we do not stock this item at the North American warehouse. Check this link to see what items we stock, or send us an email to discuss.

Our Global warehouse can make any rim model and ship worldwide. Please fill out this form with your special requests if you want custom rims/wheelset. We will get back to you via email to discuss in 24hrs.

Shopping Style

Options Features	Quick Buy	Full Custom
Options Features	Inventory	Parts in stock (Assembled upon order)	Manufactured upon order
Customization	Least customizable	100% Customizable
Lead Time	≤ 3 days	4 weeks typically
Availability	Limited models	All models
Shipping	Worldwide	Worldwide

Quick Buy (In Stock)

Full Custom (Made to Order)

DEFAULT SETTINGS

Rims

Hook, matte, UD, with drain holes

Hook, matte, UD, with access holes, with drain holes

Standard, hook, paintless, UD, 5-year warranty, with access holes, with drain holes

Front Flyweight / Rear Standard, paintless, UD, 5-year warranty, no drain holes

Paintless, UD, 5-year warranty, no drain holes

Grooved graphene surface, hook, matte, UD, with access holes, with drain holes

Grooved graphene surface, hook, matte, UD, no access holes, with drain holes

Matte UD, 32H, Centered (Staggered)

Hubs

Hope Pro 4 Fatsno J-bend 6-bolt

15/150mm (F) & 12/197mm (R) Sram XD

Straightpull centerlock black 24H

12/100mm & 12/142mm

Shimano Road 11S

DT Swiss straightpull / Bitex j-bend, centerlock, 28H

J-bend, DT Swiss 6-bolt / Bitex centerlock, 32H

15/110mm boost & 12/148mm boost Sram XD

DT Swiss straightpull / Bitex j-bend, black, 20H front / 24H rear

100mm QR & 130mm QR Shimano Road 11S

Spokes

Sapim CX Ray black

Sapim D-Light

Accessories

No decals/valves/tape

No decals/valves/tape/pads

No decals/valves

Piece Weight: g+/-

Subtotal: USD +

Lead time:

ADD TO CART

Bead type This is a required option.

Tubular

Brake System This is a required option.

Road-Rim-High-TG-Surface-Grooved-Graphene-Surface

Non Disc - High TG Surface: Rim Brake 700C road rims use an advanced High TG resin system with a layer of graphene to help dissipate heat. The braking power and reliability is significantly improved over a basalt braking surface.

Non Disc - Grooved Graphene Surface: Our new resin system and construction method, combined with the 3k rim track, withstands over 280°C, dissipates heat, and lowers rim temperatures faster in between braking efforts. Gain confidence-inspiring brake performance on the steepest descents and wettest conditions with our matching brake pads. Also, graphene added to the rim brake track allows for greater resistance to overheating with improved heat dissipation and reduced temperature accumulation during heavy braking. The grooved track helps evacuate trapped moisture between pad and rim in wet conditions, and brings more resistance and force at the lever when conditions are dry.

Full Custom: This option (if provided here to choose) offers custom braking track in other various weaves (UD/12K/3K twill etc) with 1-2 weeks LONGER on manufacture and extra $10USD/rim only as a start (with High TG Surface by default). If you select this option and LEAVE YOUR TAILORED REQUIREMENT IN THE NOTES AT CHECKOUT, we will reach out to you once the order is placed.

Disc: The disc version does not have a rim brake track and features a unique disc specific layup process. Our new layup is about 10g ~30g lighter by reducing the unnecessary material and utilizing elements of our Flyweight construction method.

Non Disc - High TG Surface

Non Disc - Grooved Graphene Surface USD +30

Full Custom USD +10

Hole Count This is a required option.

Please note that our valves are drilled for presta and spoke holes are made for external nipples by default.

Full Custom: This option (if provided here to choose) offers custom drilling for any other hole counts or special drilling (e.g G3/ 2:1 etc), most of which are at no extra charge. If you select this option and LEAVE YOUR TAILORED REQUIREMENT IN THE NOTES AT CHECKOUT, we will reach out to you once the order is placed.

20H

24H

28H

32H

Full Custom

Finish This is a required option.

Matte is slightly lighter and a more subtle finish (most popular). Glossy has a shine to it.

Full Custom: This option (if provided here to choose) offers custom finish such as Satin/Raw etc at no extra charge but subject to rim models with 3-5 days LONGER on manufacture. And custom color painting is also available with added 15g/rim and extra $20USD/rim as a start. If you select this option and LEAVE YOUR TAILORED REQUIREMENT IN THE NOTES AT CHECKOUT, we will reach out to you once the order is placed.

Glossy

Matte

Full Custom

Weave This is a required option.

The layup schedule is predetermined for each model, but you can choose the outer layer for cosmetic appearence.

The rim strength & weight is virtually identical.

Matte UD is the most popular and has a subtle look.

The futuristic Hexa-Comb and Braided UD are smooth and looks great on deep rims.
More info about Weave >>

Full Custom: This option (if provided here to choose) offers custom weaves such as 3k twill vertical/ horizontal/ Braided UD etc with extra charge of $15USD/rim as a start but subject to rim models with 3~5 days LONGER on manufacture. If you select this option and LEAVE YOUR TAILORED REQUIREMENT IN THE NOTES AT CHECKOUT, we will reach out to you once the order is placed.

12K

Hexa-Comb USD +15

Full Custom USD +15

Center Channel Hole This is a required option.

With Access Holes: This is the traditional method. Spoke access holes are drilled in the center channel to allow the nipples to easily be fed through the rim. Tubeless tape is required to seal the rim.

No Access Holes: No spoke access holes are drilled in the center channel. Feeding the nipples through the rim is more challenging, but it allows for a tubeless setup without the need for tape. This kind of system is known as "road tubeless" and was made popular by Mavic. Some companies still refer to it as "UST style", however, UST is actually a specific interface between the tire and rim which was developed by a partnership between Mavic, Michelin, and Hutchinson.

Currently, rims with 'No Access Holes' do not work with our carbon spokes.

With Access Holes

No Access Holes

Drain Hole This is a required option.

The two small drain holes located 90° to the valve hole effectively help evacuate both the water trapped inside the rim and the air leaking into the rim chamber caused by nonperfect tubeless tape sealing handwork that may risk rim explosure in an aggressive tire inflating.

It is the small reinforced layer prelaminated on the area where the drain hole is drilled later that makes the rim strength fairly ensured without any compromise of weight added.

Riders who ride in wet areas are suggested to order rims with drain holes.
More info about holes >>

With Drain Holes

No Drain Holes

Decal This is a required option.

Road rims use super light waterslide decals (matte colors). The decal is very thin and applied under a clearcoat so they are non-removeable.

Pictures about light-bicycle decal >>

If you want custom graphic, Please email us, we will design for you. There will be extra cost for custom graphic on rims.

Pictures about custom graphics >>

Blank (No decal)

Stealth (Grey)

Blue

Green

Magenta

Orange

Red

White

Yellow

Brake Pads This is a required option.

By default, Shimano type is offered only (Contact us if you want Campagnolo type). 4 pads will be included. These high performance brake pads are designed for carbon bike rims only and offer excellent stopping power even in the wet.
Instructions of brake pads

None

Add Shimano-type Brake Pads USD +10

tubular-climbing-light-weight-carbon-rim

Recon Pro orders start shipping in October.

- + PCS

Piece Weight: 360.00g+/-15

Subtotal: USD 148+

PREVIOUS NEXT

RIM SPECS

Rim Model R35T
Material Toray T700 & T800 Premium Carbon Fiber
Size 29”/700C (ETRTO 622mm)
Series FALCON
Intended Use Road/CX
Bead Type Tubular
Outer Width 25mm
Depth 35mm
ERD 570mm (not including nipple head dimension)
Rim Weight 360 +/-15g
Profile Symmetric (0mm)
Max Cyclist Weight (on flat ground) 120kg/ 265lbs
Spoke Hole Angle ±5°
Spoke Tension 100 ~115kgf front, 120~135kgf rear drive side
Recommended Tire Width 21C-38C

Rims

Our Pro series comes with a 5-year warranty (lifetime optional), while the non-pro with a 3-year warranty and crash replacement.)

Rim Model: R35T
Material: Toray T700 & T800 Premium Carbon Fiber
Size: 29”/700C (ETRTO 622mm)
Series: FALCON
Intended Use: Road/CX
Bead Type: Tubular
Outer Width: 25mm
Depth: 35mm
ERD: 570mm (not including nipple head dimension)
Rim Weight: 360 +/-15g
Profile: Symmetric (0mm)
Max Cyclist Weight (on flat ground): 120kg/ 265lbs
Spoke Hole Angle: ±5°
Spoke Tension: 100 ~115kgf front, 120~135kgf rear drive side
Recommended Tire Width: 21C-38C

Full Custom

Get in touch with us (sales@lightbicycle.com) to discuss in detail your customization request.

Hole: Hole Count, Spacing, Pattern, Drilling Angle, Diameter
Finish: Matte, Glossy, Satin, Colored Paint
Weave: UD, 3K, 3K Twill (Vertical/Horizontal), 12K, 12K Twill (Vertical/Horizontal), Braided UD, Hexa-Comb
Brake Track: UD, 3K, 3K Twill (Vertical/Horizontal), 12K, 12K Twill (Vertical/Horizontal), Braided UD, Hexa-Comb
Weight Style: Standard, Flyweight, Ultra-Light, Heavy Duty, HD+

Explore more Full Custom services

Please carefully inspect your package when unboxing it and contact us immediately if it is damaged or if anything is missing.

Together we can make this planet better. Join our sustainability program to reduce paper waste using digital docs.

Download user guides >>

Overview

Coming in at only 360g per rim, the R35 is designed to help you soar up the climbs while still given you that aerodynamic edge when the road becomes flat. The 17.9mm internal width works with anything from a 23mm to 33mm road or Cyclocross tire.
Specs
Rims

Rim Model: R35T

Material: Toray T700 & T800 Premium Carbon Fiber

Size: 29”/700C (ETRTO 622mm)

Series: FALCON

Intended Use: Road/CX

Bead Type: Tubular

Outer Width: 25mm

Depth: 35mm

ERD: 570mm (not including nipple head dimension)

Rim Weight: 360 +/-15g

Profile: Symmetric (0mm)

Max Cyclist Weight (on flat ground): 120kg/ 265lbs

Spoke Hole Angle: ±5°

Spoke Tension: 100 ~115kgf front, 120~135kgf rear drive side

Recommended Tire Width: 21C-38C

Read more for actual road tire width

Full Custom

Get in touch with us (sales@lightbicycle.com) to discuss in detail your customization request.

Hole: Hole Count, Spacing, Pattern, Drilling Angle, Diameter

Finish: Matte, Glossy, Satin, Colored Paint

Weave: UD, 3K, 3K Twill (Vertical/Horizontal), 12K, 12K Twill (Vertical/Horizontal), Braided UD, Hexa-Comb

Brake Track: UD, 3K, 3K Twill (Vertical/Horizontal), 12K, 12K Twill (Vertical/Horizontal), Braided UD, Hexa-Comb

Weight Style: Standard, Flyweight, Ultra-Light, Heavy Duty, HD+

Explore more Full Custom services
Warranty

For Non-Pro Series Rims: From the date of purchase, 3-year Standard Warranty.

For Pro Series Rims: From the date of purchase, 5-year Pro Warranty as standard and an upgraded optional lifetime Premium Warranty with minimum charge.

Crash Replacement: It is applicable with the same period as the warranty time range that you purchased for the rims with 10% /25% discount for Non-Pro series /Pro series.

Learn More >>
In The Box

Please carefully inspect your package when unboxing and get in touch with us immediately if the package is damaged or anything is missing.

Together we can make this planet better. Join our sustainability program to reduce paper waste with the use of digital manuals.

Download user guides >>

Gallery

Stephen : from Coonamessett Farm Eco Cross in Falmouth, MA. The wheels are working out great and running low pressure was key today!

USA

View More Reviews >>

COMMENTS

Tomas 2018/11/22

Hello, would be possible to order 1pcs of rim RRU35T02 for 22 holes meant for the nipples? https://www.lightbicycle.com/35mm-deep-tubular-super-light-25mm-wide-rims-700C-with-basalt-braking-surface.html Thank you in advance for your feedback. Best regards Tomáš Kulhavý

LightBicycle 2018/11/23

Hi Tomas, Yes, we can customize 22 spoke count on this road tubular rim for you. Thanks, Lightbicycle

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

Sam 2018/10/26

I weigh 64kg and I want these rims for disc brake, what is the lightest they can be made?

LightBicycle 2018/10/30

Hi Sam, The road disc version of RRU35T02 (25mm wide, 35mm deep, tubular) is 360g+/-15. Our rims are full handbuilt, so there's a tolerance window to the weight. If you are looking for a light profile. I can mark to our factory to make the rim as light as possible for you. under 360g. Is this ok with you? Pls note that the recommended tire width is 23~38c. Thanks, Lightbicycle

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

Alistair 2018/10/13

would your 35mm depth 25mm width carbon tubular disc rims beck for mud and dry cyclocross races,

LightBicycle 2018/10/15

Hi Alistair, We will have 28mm wide/36mm deep tubular rims. Does it work for your cyclorcross bike? Thanks, Lightbicycle

takashi 2018/10/29

Do you have that product in stock? (width 28mm, deep 36mm, cyclocross) Please email me. Best regards.

LightBicycle 2018/10/30

Hi Takashi, Usually, we don't have road bike rims in stock. The production for rims is 12 days, will this time window be ok with you? Thanks, Lightbicycle

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

Sam 2018/10/26

I weigh 64kg and I want these rims for disc brake, what is the lightest they can be made?

LightBicycle 2018/10/27

Hi Sam, The disc version of RRU35T02 road disc(25mm wide, 35mm deep, tubular) is 360g+/-15. Our rims are full handbuilt, so there's a tolerance window to the weight. If you are looking for a light profile. I can mark to our factory to make the rim as light as possible for you. under 360g. Is this ok with you? Thanks, Lightbicycle

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

alyosha 2018/07/31

what is the internal width of the rim if I want to set them up tubeless? thanks

LightBicycle 2018/08/01

Hi Alyosha, The RRU35C02 (17.9mm inner/35mm outer width, clincher) is the one that you looking for since you want to set up a tubeless wheelset. You can see the rim profile from the attachment. Thanks, Lightbicycle

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

Stephen 2018/03/11

Hi I am considering ordering the ‘disc brake’ version of this rim (35mm tubular). Is it possible to use some more layers of carbon fibre to make the tyre-bed more impact resistant (for cyclocross use)? Do you use standard or ‘high tg’ resin for the disc brake version of this rim? Also, can you post the rims to Australia, and how long would it take for them to arrive? Thanks

LightBicycle 2018/03/12

Hi Stephen, We can make a heavy duty version for RRU35T02, adding 50g material for one rim. For our U-shape rims with brake surface, we use High TG resin for the brake surface. Base on our lab experiment data, it can take over 240-degree heat. If you order disc rims, the resin will not be high TG resin. Of course, we can ship to Australia. The heavy-duty version rim is a special order, so it would take 12 days when you place the order. Another 3~5 days to delivery to you. Thanks, Lightbicycle

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

Ignace 2017/12/10

Hi, it is possible to have two lightest RRU35T02 rim in 3k glossy 24/28 disc ? How much weight the lightest rims from this model ? Are they ok for me and my 85kg for cyclocross ?

LightBicycle 2017/12/11

Hi Ingace, We can manufacture the lighter RRU35T02 rims (3k glossy, 24H/28H) for you. It will be around 335g, does that work for you? You are not a large rider, so the rim is strong enough for your riding. Thanks, Lightbicycle

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

José 2017/11/15

Hello You can choose the decals of the item no. rg922 Thank you

LightBicycle 2017/11/16

Dear José, For graphic, we have attached newest road decal(not removable) and newest stickers(removable) for your choice. Or do you like no graphic? Thanks, Lightbicycle

LightBicycle 2017/11/16

Dear José, For graphic, we have attached newest road decal(not removable) and newest stickers(removable) for your choice. Or do you like no graphic? Thanks, Lightbicycle

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

Reid 2017/11/07

What is the price to have these built with Novatec disc hubs? Do the novatec hubs have replaceable end caps for use with different axles (ie. qr and 15mm thru)? Thank you,

LightBicycle 2017/11/08

Hi Reid, For end cap, do you mean adaptor(as attached)? If yes, which axle size do you want? D791SB/D792SB from 15*100mm to 100mm QR? Thanks, Lightbicycle

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

Rob 2017/06/28

How much to post a single rim 700c 35mm tubular to New Zealand please

LightBicycle 2017/06/29

Hello Rob, Thanks for your inquiry. Please find our quotations as below. All pricing in USD. -RRU35T02 (tubular rim): 360 /-15g, $145/pcs -WR38T02 rear wheel (with DT 350 non-disc hub, Sapim cx-ray spokes): $363/pcs -Delivery cost: $58.40 for one rim or $77.80 for one wheel to New Zealand by EMS Please let us know if there is any other questions. Thanks, Lightbicycle

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

S 2016/10/15

Do you have a 35mm U shape rim tubular ud matte finish 28 hole with or without braking surface in stock/already made or would I have to wait to have one built before being shipped? Estimated total wait time? Regards, S

Light-Bicycle 2016/10/17

Hello Sir, Thanks for your inquiry. Sorry, we don’t have any road rims in stock. It takes 12 days for rims manufacturing. And EMS delivery takes another 4-7 days to arrive. Does it work for you? Thanks, Light-bicycle

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

Henrik 2016/08/31

Hi What is the weight for the 35 mm U-shape rim for disc (with out breaking surface) ?? Best regards Henrik

Light-Bicycle 2016/09/01

Hello Henrik, The U35mm tubular rim without brake track is 350 /-15g. Thanks, Light-bicycle

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

david 2016/08/13

Hi, Is it possible to get them with dt 350 hubs and get both 12x135mm and 12x142mm endcaps for the rear wheel and 12x100m for the front wheel? Wheelset look like this: 35mm tubular rims 28h non braking track ud finish no decals 28h dt350 hubs centerlock straigtpull. 12x100m front, 12x142mm rear 12x135mm endcaps 11spd shimano black dt spokes black brass nipples cost with shipping to sweden? Delivery time? Regards David

Light-Bicycle 2016/08/15

Hello David, Thanks for your inquiry. Currently, only DT 350 front 15mm TA/ rear 12*142mm TA are available. We don’t have the convert kit for 12*135mm TA here, and the front 12*100mm will be available around 2 months later. Is it too long for you to wait it? Or you can order the rims only and build the wheels and buy the convert kits at your local shops. Thanks, Light-bicycle

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

FuelForThought 2016/07/31

Please quote RRU35T02, Disc only (no brake track), Matt UD, front 28H/rear 28H, black Sapim CX-Ray, black alu nipples, DT240s straight pull, centerlock rotor, 12x142 rear axle, 15x100 front axle. Could you also quote the price with DT350s instead of DT240s?

Light-Bicycle 2016/08/01

Hello Fuel, Thanks for your inquiry. Please find our quotations as below. WRU35T02 (with DT 240S disc hubs): $935/pair WRU35T02 (with DT 350 disc hubs): $730/pair Thanks, Light-bicycle

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

Jai 2016/06/19

Hi, Can you do these rims centre drilled (with non-angled holes) for triplet lacing (like Fulcrum wheels)? Or even better angled holes 2 drive side, one non-drive side. Many thanks,

Light-Bicycle 2016/06/20

Hello Jai, Thanks for your inquiry. For center drilling, do you like the rims with offset or drilling in center line? For Fulcrum wheels, they use 2:1 drilling. Please find attached pictures. Is that what you like? Method A or Method B? How many spoke holes do you like for front & rear? Thanks, Light-bicycle

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

See all 17 customer reviews>>

Get in touch

Feel free to leave a comment if you have any questions or suggestions on our products or other issues.

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

Build Your Falcon RIM R35T

Overview

Specs

Warranty

In The Box

Rims

Full Custom

Overview

Specs

Rims

Full Custom

Warranty

In The Box

Gallery
